E26 adjustable base 12V AC RGB switch ON / OFF control 17W PAR56
aluminum LED pool light
Product details
1. IP Rate: IP68 Structural waterproof.
2. CD12 Die-cast aluminum material shell, great heat dissipation
through structure.
3. Aluminum material +ANTI UV PC cover, no yellowing or dazzling
for two years.
4. Swimming pool rgb led light bulb 12v E26 must assemble to IP68
Niche/Housing.
5. Adjustable height patented design, PAR56 bulb can perfectly
match with the niches of Pentair, Jandy, Hayward, etc.
Product Features
1. IP68 led pool light has Anti-UV transparent PC cover, won't turn
yellow within 2 years.
2. Constant current driver, comply with CE & EMC standard.
3. The copper GX16D base, great electrical conductivity.
4. Nickel-plated copper terminal block, E26 connector/GX16D
Connector.
5. High-quality 2.0MM thickness, 2.0W / (m.k) thermal conductivity
aluminum substrate.
Specification
| HG-P56-18W-B-RGB(E26-L)-T |
| Lamp paramater | Material | Aluminum+Anti UV PC cover |
| Light dimension | Φ165×125-138mm |
| Input voltage | AC12V |
| Wattage | 17W±10％ |
| Light lumen | 520LM±10％ |
| Beam angle | 120° |
| BASE | E26 |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120/220V coil transformer |
|
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED PAR56 swimming pool lights (Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 62 | 65 |
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Light pool ip68 must be 8 hours aging test.
3. Finished products all passed 30 steps quality inspection
4. Good looking stamping SS316 rivet screws, more stable, never
fall off
5. Good looking with rivet screw and cover nut assembly, longer
lifespan.
6. IP68 structure waterproof, can long time use underwater.
Application
led salt water pool light application: Concrete pool ,Vinyl pool
,Outdoor Swimming Pool,
family pool,hotel pool, underwater etc.
led salt water pool light construction drawing
Packing List
| Item | HG-P56-18W-B-RGB(E26-L)-T |
| Product weight | 800G |
| color box size | 185×185×118mm |
| Carton/pcs | 20pcs/Carton |
| Carton size | 610x410x410mm |
| Carton weight | 26.8KG |
