Surface Mount Led Light 18W IP68 Waterproof LED Lights Underwater
Spot Light
Product details
1. IP Rate: IP68 Structural waterproof.
2. Anti-UV PC cover, excellent yellowing resistance, and durable
3. Environmental ABS material shell, 7 colors for optional.
4. Nylon+Fiber material base shell, good toughness and
aging-resistant
5. RGB Switch control and synchronous control are the best selling
control in Heguang.
Product Features
1. 18w swimming pool lights has transparent PC cover, uniform
lighting no dazzing.
2. Engineering ABS material,multiple color for option.
3. Waterproof lights for swimming pool has high tension waterproof
silicone ring.
4. QC led surface mounted pool lights with Nylon+fiber plastic back
cover, good toughness and anti-aging ability;
5. 2-3MM aluminum light board for excellent heat dissipation,
2.0W/(m.k) Thermal conductivity.
Specification
| HG-PL-18W-C1 |
| Lamp paramater | Material | ABS + Transparent PC cover |
| Light dimension | Φ290×49.5mm |
| Input voltage | AC12/DC12V |
| Wattage | 18W±10％ |
| Light lumen | 1400LM±10％ |
| Halogen replacement | 120W |
| Beam angle | 120° |
| BASE | Wire out |
| CCT | Pure White: 6500±10% Warm White:3000K±10% costomized |
| Wave Length (nm) | R: 621-625nm |
| G: 518-520nm |
| B: 464-467nm |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Test position | LED Surface Mounted Swimming Pool Light(Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 67 | 70 |
LED swimming pool light compared to others
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Concrete swimming pool lamp must be 8 hours aging test.
3. Finished products all passed 30 steps quality inspection
4. IP68 structure waterproof ,can long time use underwater.
5. Constant current driver, comply with CE & EMC standard.
LED swimming pool light all passed 30 steps quality control , 100% waterproof at 10m depth,
8 hours LED agening test, 100% inspection before deliver.
Application
Surface mounted pool lights application: Concrete pool ,Vinyl pool
,Outdoor Swimming Pool ,family pool,hotel pool ,underwater etc.
Packing List
| Item | HG-PL-105S5-C1-WW |
| Product weight | 110G |
| color box size | 185×185×118mm |
| Carton/pcs | 20pcs/Carton |
| Carton size | 610x410x410mm |
| Carton weight | 26.8KG |
FAQ
1. Q: When can I get the price?
A: We usually quote within 24 hours after got your inquiry. If you
are urgent to get the prices,
please call us directly or leave us the messge ,we will give priority to your inquiry.
2. Q: May I get samples to test quality and how long can I get
them?
A: Yes, samples can be ready in 3-5 days.
3. Q: What is the MOQ?
A: NO MOQ, the more you order ,the cheaper price you will get .
4. Q: Can you accept small trial order?
A: Yes
5. Q: Do you accept the OEM&ODM?
A: Yes, OEM/ODM acceptable.
6.Q:what's the RGB control you have?
A: Patent design RGB 100% synchronous control ,switch control
,external control ,wifi control ,DMX512 control,etc.
