Product details
1. All product provide Warranty 2 years.
2. Environmental ABS material shell.
3. IP68 Structure waterproof, without resin-filled.
4. Patented 4-layers waterproof structure, more stable than
resin-filled pool lights.
5.Fiberglass pool light assembly completely replace traditional
pool lights and modern pool lights.
| HG-PL-18X1W-F1-RGB-T |
| Lamp parameter | Material | ABS + Transparent PC cover |
| Light dimension | Φ290×85mm |
| Input voltage | AC12 |
| Wattage | 18W±10％ |
| Light lumen | 630LM±10％ |
| Beam angle | 120° |
| BASE | Wire out |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120/220Vcoil transformer |
|
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED Surface Mounted Swimming Pool Light(Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 46 | 57 | 65 | 65 | 56 | 66 | 68 | 70 |
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Must be 8 hours aging test.
3. Finished products all passed 30 steps quality inspection
4. IP68 structure waterproof, can long time use underwater.
5. Constant current driver, comply with CE & EMC standard.
Application
Surface mounted pool lights application: Concrete pool ,Vinyl pool
,Outdoor Swimming Pool, family pool,
hotel pool, underwater etc.
FAQ
1. Q: When can I get the price?
A: We usually quote within 24 hours after got your inquiry. If you
are urgent to get the prices,
please call us directly or leave us the messge, we will give
priority to your inquiry.
2. Q: May I get samples to test quality and how long can I get
them?
A: Yes, samples can be ready in 3-5 days.
3. Q: What is the MOQ?
A: NO MOQ, the more you order, the cheaper price you will get.
4. Q: Can you accept small trial order?
A: Yes
5. Q: Do you accept the OEM&ODM?
A: Yes, OEM/ODM acceptable.
6.Q:what's the RGB control you have?
A: Patent design RGB 100% synchronous control ,switch control
,external control ,wifi control ,
DMX512 control,etc.
