Product details
1. Working Voltage: must use AC12V coil transformer.
2. Private Mode products,support ODM&OEM.
3. IP68 Structure waterproof, without resin-filled.
4. RGB led swimming pool light price completely replace traditional
pool lights and modern pool lights;
5. Material: Engineering ABS material+ANTI UV PC cover,no yellowing
or dazzling for two years.
6. RGB Switch control and synchronous control are the best selling
control in Heguang.
7. Patented 4-layers waterproof structure, more stable than
resin-filled pool lights
8. VDE standard rubber wire, connected with IP68 nickel-plated
copper connector.
9. All products succeeded in 10m deep water testing before
delivery.
10. Swimming pool led light rgb need 8 hours aging testing, 30
steps quality inspections, assure the great quality pool light.
11. Constant current driver, comply with CE & EMC standard.
Specification
| HG-PL-12W-V-RGB-T |
| Lamp parameter | Material | ABS + Transparent PC cover |
| Light dimension | Φ250×135.5mm |
| Input voltage | AC12 |
| Wattage | 12W±10％ |
| Light lumen | 250LM±10％ |
| Beam angle | 120° |
| BASE | Wire out |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120/220V coil transformer |
|
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED Surface Mounted Swimming Pool Light(Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 67 | 70 |
Application
IP68 vinyl light pool application :Concrete pool, Vinyl pool,
Outdoor Swimming Pool, familypool,hotel pool ,
underwater etc.
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Above ground swimming pool Must be 8 hours aging test.
3. Led underwater lights finished products all passed 30 steps
quality inspection
4. IP68 structure waterproof, can long time use underwater.
5. Constant current driver, comply with CE & EMC standard.
FAQ
1.How to get a sample?
-Based on the value of our products, we do not supply free sample,
if you need a sample for testing,
please kindly contact our sales for more details.
2.How long to deliver the products?
-The exact delivery date need to according to your model and
quantity. Usually within 5-7 working
days for sample after receive the payment and 15-20 working days
for mass production.
4.How to deal with the faulty products?
-Firstly, our products are produced in strict quality control
system and the defective rate will be less
than 1%.Secondly, during the guarantee period,we will send new
replacement with new order for small
quantity.. For defective batch products, we will repair them and
resend them to you or we can discuss
the solution including re-call according to real situatio.
