    50Hz / 60Hz Toroidal Type Transformer 2000W Higher Energy Conversion Efficiency

    Ask Lasest Price
    Brand Name : Birmate
    Model Number : HG-12AC-2000W
    Certification : CE,RoHS,FCC
    Price : negotiation.
    Payment Terms : Paypal,L/C,T/T,etc.
    Supply Ability : 10000 pcs per month
    Delivery Time : 7-10 working days
    • Product Details
    • Company Profile

    50Hz / 60Hz Toroidal Type Transformer 2000W Higher Energy Conversion Efficiency



    2000W AC12V output voltage LED power 220V input voltage LED toroidal transformer

    Specifications

    HG-12AC-2000W
    Product FeaturesLong-lifeHigh silicon iron core+Full copper winding
    Energy-conservingSmaller no-load standby loss
    High efficiencyHigher energy conversion efficiency
    High standardDouble insulated enameled wire winding
    High qualityStandardized winding process and welding level
    Electrical characteristicsFull Loading Power2000W(MAX)
    Input VoltageAC220V±10%
    Frequency50Hz/60Hz
    Full Loading Current166.6A(MAX)
    Shape ParametersProduct volumeExternal diameter 207mm*Internal diameter63mm*H85mm
    Mounting plateStandard 200*200mm
    Hole distance170*170mm(Center distance)
    Pore size5*8mm(Elliptical hole)
    G.w./pc14.9kg
    IP ratingIP20


    Dimension

    50Hz / 60Hz Toroidal Type Transformer 2000W Higher Energy Conversion Efficiency50Hz / 60Hz Toroidal Type Transformer 2000W Higher Energy Conversion Efficiency50Hz / 60Hz Toroidal Type Transformer 2000W Higher Energy Conversion Efficiency
