GX16D base aluminum AC 12V RGB switch ON / OFF control 18W PAR56
LED pool light
Product Quick detail
1. Anti-UV transparent PC cover, won't turn yellow within 2 years.
2. Pool lights led underwater dayagram Shinning angle:120°.
3. Aluminum material +ANTI UV PC cover,no yellowing or dazzling for
two years.
4. CD12 Die-cast aluminum material shell, great heat dissipation
through structure.
5. Adjustable height patented design, PAR56 bulb can perfectly
match with the niches of Pentair, Jandy, Hayward, etc.
Product features
1. Underwater light poolled GX16D fireproof plastic cable.
2. Same size as traditional PAR56 light, fully compatible with
GX16D swimming pool light.
3. Nickel-plated copper terminal block, E26 connector/GX16D
Connector
4. Pool led lights underwater adapted to American
lamps:pentair/AUSTRAL/Haywad etc.
5. 90% Transparent PC cover , light transmittance ＞90%.
6. Nickel-plated copper terminal block, E26 connector/GX16D
Connector.
Specification
| HG-P56-18×1W-B-RGB(GX16D-L)-T |
| Lamp paramater | Material | Aluminum+Anti UV PC cover |
| Light dimension | Φ177×118mm |
| Input voltage | AC12V |
| Wattage | 18W±10％ |
| Light lumen | 630LM±10％ |
| Beam angle | 15°/30°/45°/60° |
| BASE | GX16D |
| CCT | RGB |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, ROHS,FCC, IP68,VDE |
| Life-span | 50,000 hours |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Connect our RGB 100% Synchronous Controller | Input Voltage | AC110/120/220V coil transformer |
|
| Wattage | 1.5W |
| cable | 2 wires |
| Control way | Synchronous control effect |
| Test position | LED PAR56 swimming pool lights (Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 62 | 65 |
Dimension
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. Underwater pool light bulbs Must be 8 hours aging test.
3. Underwater light for pool Finished products all passed 30 steps
quality inspection.
4. Good looking stamping SS316L rivet screws, more stable ,never
fall off.
5. Good looking with rivet screw and cover nut assembly,longer
lifespan.
6. IP68 structure waterproof, can long time use underwater.
Application
HG-P56-18×1W-B-RGB(GX16D-L)-T led pool lighting widely use in concrete pool ,
vinyl pool, the lamp size can totally match various Germany and US
PAR56 housing/niches.
Confirm product & label
Packing list
| HG-P56-18×1W-B-RGB(GX16D-L)-T |
| Package | Light dimension | Φ177×118 mm |
| G.W. / pc | 1020g |
| Carton dimension/ Qty./ctn | 680×410×410 mm/ 20pcs/ctn |
| G.W. / ctn. | 22.1kg |
| Connect RGB Synchronous Controller | Input Power | AC12-15V coil transformer |
| Input Voltage | AC12-15V |
| Wattage | 1.5W |
| Base | GX16D base |
| Control way | Synchronous control effect |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
Some tips for you
Q1: How to choose the right LED energy saving lamps?
Low watage with high Lumen. This will save more electricity bill.
Q2: What is the advantages of LED?
Environmental friendly, Energy saving and Long lifespan.
Q3: The key factor that influence LED lifespan.
Temperature: It requires that junction temperature of LED chip
should be ≤120℃,
so the center temperature at the LED bottom of light board should
be ≤ 80 ℃.
Q4: Why choose us?
1. Lower wattage with high Lumen and more energy-efficient.
2. All lamps are self-developed patent products.
3. IP68 structure waterproof without glue, and lamps disspate heat
through structure.
4. According to the LED characteristic, the center temperature at
the LED bottom of light board must be controlled strictly( ≤ 80 ℃).
5. High quality driver of lamps to ensure the long lifespan.
6. All products have passed CE, ROHS, FCC, IP68, and our Par56 pool
light have got UL certification.
7. All products need to pass 30 steps QC inspection, the quality
has the guarantee, and the faulty rate is less than three per
thousand .
