Product Quick detail
1. Working Voltage:AC/DC 12V input.
2. Private Mode products, power pass CE certified.
3. Pool lights led underwater is IP68 Structural waterproof.
4. Aluminum material +ANTI UV PC cover, no yellowing or dazzling
for two years.
5. Underwater swimming pool lights with 316L Stainless steel +anti
UV PC cover.
Product Features
1. Constant current power driver,EMC anti-interference circuit.
2. Pool underwater light are 316 stainless steel screw assembly.
3. Underwater light pool are IP68 Structural waterproof, no
yellowing or dazzling for two years
4. Swimming pool light led underwater can fully match the market's
conventional PAR56 lamps,
replacing halogen Light.
5. Solar pool light underwater with anti UV PC cover, Uniform
light, no yellowing or dazzling for two years.
Specification
| HG-P56-18X3W-C |
| Lamp parameter | Material | SS316L + Anti-UV PC cover |
| Light dimension | Φ177×102mm |
| Input voltage | AC/DC12V |
| Wattage | 25W±10％ |
| Light lumen | 1750LM±10％ |
| Halogen replacement | 150W |
| Beam angle | 15°/30°/45°/60° |
| BASE | two screws terminal |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Warranty | 2 Years |
| !!! Remarks | Connect coil transformer | must be coil transformer |
| Waterproof ring of housing | must do right to get IP68 |
| Test position | LED PAR56 swimming pool lights (Min) |
| Working temperature 28℃ | Working temperature 40℃ |
| Underwater test time(Min) | 480 | 480 |
| LED edge temperature(℃) | 70 | 73 |
Advantage
1. Constant current power supply driver, EMC anti-interference
circuit.
2. Led underwater pool light assembly with SS316 screws,more durable.
3. PC material LED lens with bracket, high heat resistance.
4. Swiming pool light led underwater Wattage below 18W, UL listed.
5. IP68 structure waterproof, whithout glue filled ,no color
temperature fading.
6. Pool light underwater diameter 177mm,can totally meet various PAR56
housing/niche:Pentair,Austra,Hayward,etc.
Application
HG-P56-18x3W-C led pool lighting widely use in concrete pool,vinyl pool, the lamp size can totally match
various Germany and US PAR56 housing/niches.
Packing List
| Item | HG-P56-18x3W-C LED pool lighting |
| Product weight | 1030g |
| color box size | 185×185×118mm |
| Carton/pcs | 20pcs/Carton |
| Carton size | 610x410x410mm |
| Carton weight | 24kg |
FAQ
1. Q: When can I get the price?
A: We usually quote within 24 hours after got your inquiry. If you
are urgent to get the prices,
please call us or tell us your email, we will give priority to your
inquiry.
2.Q: Why choose your factory?
We in led pool lighting over 13years, We have own professional
R&D and production and sales team.
we are the only one China supplier who is listed in UL certificate
in Led Swimming pool light industry.
3. Q: Do you accept the OEM&ODM?
Yes, OEM or ODM service are available.
4. Q: What is the MOQ?
A: NO MOQ, the more you order ,the cheaper price you will get.
5.Q: Do you offer guarantee for the products?
A: Yes, we offer 2 years warranty to our products.
6.Q:how can i get my package?
After we send the products,12-24hours we will send tracking number
to you ,then you
can track your products on your local express website.
