9W recessed stainless steel led color changing 24 volt ip68
waterproof lights
Product details
1. All products provide 2 year warranty.
2. IP Rate: IP68 Structural waterproof.
3. Private Mode products,Support ODM&OEM.
4. VDE standard outlet: standard cable length is 1 meter.
5. 316L Stainless steel material, super good anti-corrosion.
6. RGB external control and DMX512 control are the best selling
control in Heguang.
Specification
| HG-UL-9W-SMD-R-RGB-X |
| Lamp paramater | Material | SS316L body+tempered glass cover+VDE rubber cable |
| length | Φ150×87.5mm |
| Input voltage | DC24V |
| Constant Driver | yes |
| Over-current Protection | yes |
| Wattage | 9±1W Epistar |
| Light lumen | 380LM±10％ |
| Beam angle | 15°/30°/45°/60° |
| Color: | RGB(DMX512/External /Wifi control |
| Wave Length (nm) | R: 620-630nm |
|
| G:515-525nm |
| B:460-470nm |
| Specifics | Operating Temperature (℃) | -20~40℃ |
| IP Rating | IP68 |
| Certificate | CE, RoHS,FCC,IP68,IK10 |
| Life-span | 50,000 hours |
| Warranty | 2Years |
| RGB Controller | LED Underwater lights | 1.DMX512 (can get the RGB color changing synchronous) 5 wires |
| 2, external controller (can get the RGB color changing synchronous)
4 wires |
| test Site | LED Underwater light (Min) |
| Ambient temperature 28℃ | Ambient temperature 40℃ |
| Underwater test lighting time(Min) | 10 | 30 | 90 | 150 | 10 | 30 | 90 | 150 |
| Light source edge temperature(℃) | 43 | 50 | 52 | 59 | 45 | 58 | 62 | 68 |
Product Features
1. High quality wafer chip Low light decay / long life / low energy
consumption.
2. Customized IP68 waterproof nickel plated brass design,good
anti-corrosion.
3. High quality wafer chip Low light decay / long life / low energy
consumption.
4. Integrated bead lens with uniform lighting ,no dazzling,light
transmittance ＞85%.
5. LED color changing pool light with 316L Stainless steel material
,super good anti-corrosion.
6. Waterproof led light for swimming pool can adjustable angle,
adding bracket means never loose.
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. IP68 structure waterproof ,can long time use under water.
3. Good looking stamping SS316 rivet screws,more stable ,never fall
off
4. Good looking with rivet screw and cover nut assembly,longer
lifespan.
5. Colored pool lights underwater finished products all passed 30
steps quality inspection.
6. Swimming pool color changing lights must be 8 hours aging test
and provide 2 Years warranty.
LED underwater pool light all passed 30 steps quality control ,
100% waterproof at 10m depth ,
8 hours LED agening test,100% inspection before deliver.
Application
(Conventional bracket) can be suitable for underwater bracket fixing
or (with clamp) water pipe binding installation method, widely used
in garden pool, square pool, hotel pool, fountain and other
underwater lighting.
Packing List
| Item | HG-UL-9W-SMD-R-RGB-X |
| Product weight | 900G/PCS |
| color box size | 625×380×325mm |
| Carton/pcs | 50pcs/Carton |
| Carton size | 610x410x410mm |
| Carton weight | 28KG/CTN |
FAQ
1. Q: When can I get the price?
A: We usually quote within 24 hours after got your inquiry. If you
are urgent to get the prices,
please call us or tell us your email so that we will give priority
to your inquiry.
2. Q: Do you accept the OEM&ODM?
A: Yes,OEM or ODM service are available.
3. Q: May I get samples to test quality and how long can I get
them?
A: Yes, quote of sample is same as normal order and can be ready in
3-5 days.
4. Q: What is the MOQ?
A: NO MOQ , the more you order ,the cheaper price you will get.
5. Q: Can you accept small trial order?
A: Yes, no matter large or small trial order, your needs will get
our full attention. It’s our great honor to cooperate with you.
6.Q: How many pieces of lamp can connect with one RGB synchronous
controller?
A: It doesn’t depend on the power. It depend on quantity, maximum
is 20pcs. If it plus the amplifier,
it can plus 8pcs amplifier. Totally the quantity of led par56 lamp
is 100pcs. And RGB Synchronous controller is 1 pcs,
amplifier is 8pcs.
