Product details
1. Underwater led lights ip68 use Cree Led Chip.
2. Private Mode products, Support ODM&OEM.
3. 316L Stainless steel material, super good anti-corrosion.
4. Grounding fixing method default: aluminum grounding pole
(plastic grounding pole optional).
5. LED aqua lighting led underwater light with VDE standard outlet:
standard cable length is 1 meter.
| HG-UL-24W-SMD-RGB-D |
| Lamp parameter | Material | SS316L body+tempered glass cover+VDE rubber cable |
| length | Φ220×225mm |
| Input voltage | DC24V |
| Constant Driver | yes |
| Over-current Protection | yes |
| Wattage | 23W±10% Epistar |
| Light lumen | 900LM±10％ |
| Beam angle | 15°/30°/45°/60° |
| Color: | DMX512 control |
| Wave Length (nm) | R: 620-630nm |
|
| G:515-525nm |
| B:460-470nm |
| packing/ shipping | Lamp sizeInner box dimension | 230×230×118mm |
| N.W. / pc | 1750g |
| G.W. / pc | 1970g |
| Carton dimension | 480×245×500mm |
| Qty. / ctn. | 8PCS/CTN |
| G.W. / ctn. | 17.0Kg |
| RGB Controller | LED Underwater lights | 1.DMX512 (can get the RGB color changing synchronous) 5 wires 2,
external controller (can get the RGB color changing synchronous) 4
wires |
|
| test Site | LED Underwater light (Min) |
| Ambient temperature 28℃ | Ambient temperature 40℃ |
| Underwater test lighting time(Min) | 10 | 30 | 90 | 150 | 10 | 30 | 90 | 150 |
| Light source edge temperature(℃) | 43 | 47 | 48 | 48 | 57 | 61 | 62 | 62 |
Product Features
1. 316L Stainless steel material ,strong anti-corrosion ability.
2. High quality wafer chip Low light decay / long life / low energy
consumption.
3. Customized IP68 waterproof nickel plated brass design,good
anti-corrosion.
4. IK10 8mm transparent tempered glass,light transmittance ＞90%,no
effect with the LED color temperature.
5. LED underwater light with VDE waterproof cable with rubber
sleeve,resistant voltage 2000V,
temperature resistance at -40℃ to 90℃.
Advantage
1. Reliable quality with 100% 10m depth waterproof test.
2. RGB led underwater light must be 8 hours aging test and provide
2 Years warranty.
3. LED underwater pool lights finished products all passed 30 steps
quality inspection.
4. Good looking stamping SS316 rivet screws,more stable, never fall
off.
5. Good looking with rivet screw and cover nut assembly, longer
lifespan.
6. IP68 structure waterproof, can long time use under water.
LED underwater pool light all passed 30 steps quality control, 100%
waterproof at 10m depth,8 hours LED aging test,100% inspection before deliver.
Application
widely used in garden pool, square pool, hotel pool, fountain and other underwater lighting.
_
FAQ
1. Q: When can I get the price?
A: We usually quote within 24 hours after got your inquiry. If you
are urgent to get the prices,
please call us or tell us your email so that we will give priority
to your inquiry.
2. Q: Do you accept the OEM&ODM?
A: Yes,OEM or ODM service are available.
3. Q: May I get samples to test quality and how long can I get
them?
A: Yes, quote of sample is same as normal order and can be ready in
3-5 days.
4.Q: How many pieces of lamp can connect with one RGB synchronous
controller?
A: It doesn’t depend on the power. It depend on quantity, maximum
is 20pcs. If it plus the amplifier, it can plus
8pcs amplifier. Totally the quantity of led par56 lamp is 100pcs.
And RGB Synchronous controller is 1 pcs,
amplifier is 8pcs.
