Product features
1. Anti-UV transparent PC cover, won't turn yellow within 2 years.
2. Full inspection and shipment of finished products.
3. Swimming pool equipment adapted to various American and German
lamps.
4. High Power high bright LED chip.
5. Swimming pool bestway with eather resistance, aging resistance.
6. Swimming pool ladder need to test 8 hours LED agening test.
7. Finished product passed 30 steps quality inspection.
8. Cheap swimming pool tile get UL approval for some models.
9. 316L Stainless steel material with bracket lens, high
temperature and heat resistance.
Specification
| HG-P56-18W-B(GX16D-H)-UL |
Parameter | Material | Aluminum+anti UV PC cover. |
| Working voltage | AC100-240V |
| Wattage | 18W±10％ |
| Color | White/Red/Green/Blue |
| Light lumen | 1700LM±10％ |
| Product Size | Φ177×118mm |
| Working temperature | -20～40℃ |
| Led Chip | SMD2835 |
| Qty | 198PCS |
| CCT | Pure White: 6500K±10% Warm White:3000K±10% costomized |
| N.Weight | 780G |
| test Site | Underwater test lighting time(Min) |
| Ambient temperature 28℃ | Ambient temperature 40℃ |
| Underwater test lighting time(Min) | 10 | 30 | 90 | 150 | 10 | 30 | 90 | 150 |
| Light source edge temperature(℃) | 45 | 52 | 56 | 62 | 51 | 55 | 61 | 65 |
| LED | Beam angle | 120° |
| working temperature | -20～40℃ |
Product Size
Application
pool lights led underwater are application: Concrete pool, Vinyl
pool, Outdoor Swimming Pool,
family pool, hotel pool, underwater etc.
Installtion
Some tips for you
Q1:How to choose the right LED energy saving lamps?
Low watage with high Lumen. This will save more electricity bill.
Q2: What is the advantages of LED?
Environmental friendly, Energy saving and Long lifespan.
Q3:The key factor that influence LED lifespan.
Temperature: It requires that junction temperature of LED chip
should be ≤120℃, so the
center temperature at the LED bottom of light board should be ≤ 80
℃.
Q3: Why choose us?
1. Lower wattage with high Lumen and more energy-efficient.
2. All lamps are self-developed patent products.
3. IP68 structure waterproof without glue, and lamps disspate heat
through structure.
4. According to the LED characteristic, the center temperature at
the LED bottom of light
board must be controlled strictly( ≤ 80 ℃).
5. High quality driver of lamps to ensure the long lifespan.
6. All products have passed CE, ROHS, FCC, IP68, and our Par56 pool
light have got UL certification.
7. All products need to pass 30 steps QC inspection, the quality
has the guarantee, and the faulty
rate is less than three per thousand .
