Product features
1. CD12 Die-cast aluminum material shell, great heat dissipation
through structure.
2. Constant current power driver,EMC anti-interference circuit.
3. Die-casting aluminum lamp body,heat fast make LED more durable.
4. Swimming pool equipment with Nickel-plated copper terminal
block, E26 connector/GX16D Connector.
5. Adjustable height patented design, PAR56 bulb can perfectly
match with the niches of Pentair, Jandy, Hayward, etc.
Specification
| HG-P56-18×1W-B-RGB(GX16D-L)-T-UL |
| Parameter | Material | Aluminum +anti UV PC cover. |
| Working voltage | AC12V |
| Wattage/Light lumen | 18W/630LM±10％ |
| Color /Control Way | RGB/Synchronous Control |
| Product Size | Φ177×118mm |
| out Size | 680×400×400mm |
| Quantity | 18pcs*1W |
| Certificate | FCC,CE, RoHS,UL |
| N.Weight | 820g |
| test Site | Underwater test lighting time(Min) |
| Ambient temperature 28℃ | Ambient temperature 40℃ |
| Underwater test lighting time(Min) | 10 | 30 | 90 | 150 | 10 | 30 | 90 | 150 |
| Light source edge temperature(℃) | 42 | 52 | 58 | 64 | 54 | 57 | 62 | 67 |
| LED | Beam angle | 120° |
| working temperature | -20～40℃ |
Product fast Descption
1. Anti-UV transparent PC cover, won't turn yellow within 2 years.
2. 8 hours aging testing, 30 steps quality inspections, assure the
great quality pool light.
3. Constant current driver, comply with CE & EMC standard.
4. Swimming pool kids with copper GX16D base, great electrical
conductivity.
6. 2-3MM aluminum light board for excellent heat dissipation,
2.0W/(m.k) Thermal conductivity.
6. 2 Years warranty
Product Detail
Installtion
Application
LED salt water pool light application: Concrete pool, Vinyl pool,
Outdoor Swimming Pool,family pool,
hotel pool, underwater etc.
Some tips for you
Q1:How to choose the right LED energy saving lamps?
A:Low wattage with high Lumen. This will save more electricity bill.
Q2: What is the advantages of LED?
A:Environmental friendly, Energy saving and Long lifespan.
Q3:The key factor that influence LED lifespan.
A:Temperature: It requires that junction temperature of LED chip
should be ≤120℃, so the center
temperature at the LED bottom of light board should be ≤ 80 ℃.
Q4: Why choose us?
1. Lower wattage with high Lumen and more energy-efficient.
2. All lamps are self-developed patent products.
3. IP68 structure waterproof without glue, and lamps disspate heat
through structure.
4. According to the LED characteristic, the center temperature at
the LED bottom of light board
must be controlled strictly( ≤ 80 ℃).
5. High quality driver of lamps to ensure the long lifespan.
6. All products have passed CE, ROHS, FCC, IP68, and our Par56 pool
light have got UL certification.
7. All products need to pass 30 steps QC inspection, the quality
has the guarantee, and the faulty rate
is less than three per thousand .
